| JIS F3012 Air Vent Head |
|
|
 |
Marine Air Pipe Head Model: 53-ON
MARINE FLOATING DISC AIR VENT HEADS
F3012-050,F3012-065,F3012-080,F3012-100
F3012-125, F3012-150 ,F3012-200,
F3012-250，F3012-300，F3012-300，F3012-350
1. Body: Cast Iron/Ductile Cast Iron
2. Disc: St.steel
3. Vent Mesh: St.steel
4. Cap: Galvanized/St.steel
| Nominal Size |
d |
L1 |
L2 |
L3 |
H |
D |
C |
W |
Weight kgs |
| 50 |
50 |
75 |
103 |
75 |
180 |
130 |
105 |
135 |
7.4 |
| 65 |
65 |
85 |
120 |
85 |
210 |
155 |
130 |
155 |
10 |
| 80 |
80 |
90 |
153 |
100 |
245 |
180 |
145 |
190 |
16 |
| 100 |
100 |
110 |
160 |
110 |
270 |
200 |
165 |
225 |
23 |
| 125 |
125 |
130 |
195 |
130 |
310 |
235 |
200 |
265 |
34 |
| 150 |
150 |
155 |
225 |
150 |
355 |
265 |
230 |
300 |
47 |
| 200 |
200 |
200 |
295 |
180 |
440 |
320 |
280 |
400 |
72 |
| 250 |
250 |
250 |
330 |
210 |
540 |
385 |
345 |
500 |
120 |
| 300 |
300 |
300 |
370 |
240 |
620 |
430 |
390 |
600 |
178 |
