Marine approved.
CCS,ABS,BV,GL
This series compressors is main use on the large and middle marine and continent diesel engine starting,and also as the source of the compressed air for the industrial department and pressure testing
Model |
HC-265A |
Type |
Vertical Water-Cooled 2 stage Compression |
Quantity of Air Supply (m3/h) |
137 |
170 |
190 |
Pressure Rating |
3MPa 30Pa |
Stalk Power (kw) |
31 |
38 |
41 |
Rotation Rating (r/min) |
730 |
870 |
960 |
Quantity of Cooling Water(m3/h) |
1.0~1.4 |
Lubricating System |
Forced Lubrication by Gear Pump |
Lubricate Trademark |
L-DAB-100(GB12691) |
Type of Unloader |
Manual,Total closure suction type or Magnetic Unloader Valve |
Method of Driving |
Direct Coupling |
Motor |
|
|
|
Model |
Y280S-8-H |
Y280M-8-H |
Y280S-6-H |
Power (kw) |
37 |
45 |
45 |
Rotation(r/min) |
730 |
870 |
960 |
Gradeprotection |
IP44 |
Ins Class |
B |
Voltage(V) |
380 |
440 |
380 |
Frequency( HZ) |
50 |
60 |
50 |
Shape size(mm) |
1870×1000×1190 |
Weight(kg) |
~1400 |
Medium pressure, large discharge air compressor
Also offer parts
Pls contact us
|
|
